2-7/8" x 20" Demineralizing Filter Cartridge

SKU : CQE-RC-04023

In stock

Subscription details

Not sure about subscribing? Most customers tell us they signed up to stop forgetting — not to save 5%. How long this cartridge lasts depends on the dissolved solids in the water you feed it. Once the resin is spent, the dissolved solids it was holding back return, and spots and residue come with them.

Subscribe and you'll get a fresh cartridge automatically — right when the old one wears out. Cancel, pause, or change your schedule anytime in your account. No phone calls, no obligation, no fees.

A mixed bed deionizing (DI) cartridge that polishes reverse osmosis water to very low dissolved solids for technical uses.

  • Reduces dissolved solids (TDS)
  • Typical life: set by feed water TDS
  • Measures 2-7/8 x 20 in and fits a standard 2.5 x 20 in housing

Replacement cartridge, 2-7/8 x 20 in

Ultra pure water for the jobs that need it

Some uses call for water with almost nothing dissolved in it. This cartridge is filled with mixed bed deionizing resin that takes up both positive and negative ions in one pass. It does its work after reverse osmosis, as a final polish.

  • Reduces dissolved solids (TDS)
  • Mixed bed DI resin
  • Typical life: set by feed water TDS
  • Fits a standard 2.5 x 20 in housing
Demineralizing (DI) Filter Cartridge, 2-7/8 x 20, single tall slim clear cartridge with white label

What a fresh cartridge gives you

Very low dissolved solids

Takes up the small amount of dissolved minerals that reverse osmosis leaves behind.

One pass

Mixed bed resin handles positive and negative ions together.

Longer life on RO water

Fed with reverse osmosis water, the resin lasts many times longer than on tap water.

2Resin types, mixed bed
2.5GPM service flow
5%Off with Subscribe and save
USAMade in

How it works

1

Mixed bed resin

Cation and anion exchange resins blended in one cartridge.

2

Ion exchange

Dissolved ions are swapped for hydrogen and hydroxide, which combine into water.

3

Polishing stage

Best placed after reverse osmosis, where little is left to take up.

What it reduces

Designed to reduce

  • Total dissolved solids (TDS)
  • Calcium and magnesium
  • Sodium and other dissolved metal ions
  • Chloride, sulfate, nitrate and bicarbonate

Not designed for

  • Chlorine and most organic chemicals
  • Sediment
  • Bacteria and viruses

This cartridge is made for technical water, such as aquariums, humidifiers, spot-free rinsing and lab use. It is not intended as a drinking water filter.

Demineralizing (DI) Filter Cartridge, close-up of the top end with white gasket and center opening

Find your size

Match the actual size printed on your current cartridge. This one measures 2-7/8 x 20 in and fits a standard 2.5 x 20 in housing, the size used in our compact whole house systems.

Cartridge sizeFitsService flow
2-7/8 x 9-3/4 in2.5 x 10 in housing0.5 gpm
2-7/8 x 20 in (this cartridge)2.5 x 20 in housing2.5 gpm
Demineralizing (DI) Filter Cartridge, tall slim clear cartridge with 2-7/8 inch diameter, 20 inch height callouts

Specifications

Part numberCQE-RC-04023
Cartridge size2-7/8 x 20 in (actual)
FitsStandard 2.5 x 20 in housing
Service flow2.5 gpm
Typical lifeSet by the dissolved solids in the feed water
MediaMixed bed deionizing resin
Recommended feedReverse osmosis water
Operating pressure20 to 125 psi
Water temperature40 to 85°F
Made inUSA

How to replace it

A few minutes, with the wrench that came with your system.

  1. Turn off the water supply to the filter and release the pressure as your system manual directs. Place a towel or drip pan underneath.
  2. Unscrew the housing with the housing wrench and lift out the used cartridge.
  3. Wash the housing with mild soap and water and rinse it well.
  4. Check that the O-ring is clean and fully seated in its groove.
  5. Unwrap the new cartridge and set it in, centered and fully seated. If one end is marked "This End Up, Toward Cap", that end faces the cap.
  6. Screw the housing back on by hand, then snug it with the wrench. Do not overtighten.
  7. Turn the water on slowly, check for leaks, then flush the new cartridge before first use.

Timing and care tips are in the Replacement Schedule tab. Questions about fit? Contact us.

SKU CQE-RC-04023
Country of Manufacture United States
On Sale No
Write Your Own Review
You're reviewing: 2-7/8" x 20" Demineralizing Filter Cartridge
loader
Loading...

check-circle You submitted your review for moderation.

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

When to replace it

It depends on the dissolved solids in the feed water. The lower the feed TDS, the longer it lasts. Check the output with a TDS or resistivity meter and replace the cartridge when the reading no longer meets your needs.

  • Replace it when a TDS or resistivity meter shows the output no longer meets your needs.

How to replace it

  1. Turn off the water supply to the filter and release the pressure as your system manual directs. Place a towel or drip pan underneath.
  2. Unscrew the housing with the housing wrench and lift out the used cartridge.
  3. Wash the housing with mild soap and water and rinse it well.
  4. Check that the O-ring is clean and fully seated in its groove.
  5. Unwrap the new cartridge and set it in, centered and fully seated. If one end is marked "This End Up, Toward Cap", that end faces the cap.
  6. Screw the housing back on by hand, then snug it with the wrench. Do not overtighten.
  7. Turn the water on slowly, check for leaks, then flush the new cartridge before first use.

Between changes

  • Keep your reverse osmosis pre-filters and membrane current. A tired RO stage sends more dissolved solids to the DI cartridge and shortens its life.
  • Write the install date on the cartridge label or in your calendar so the next change is easy to time.

Never run late on a change. Choose Subscribe and save when you order and a fresh cartridge arrives on the schedule you set, with 5% off each delivery.

Questions about timing? Contact us.

Demineralizing (DI) Filter Cartridge FAQ

What is a mixed bed DI cartridge?

It blends cation and anion exchange resins, so it takes up positive and negative dissolved ions in one pass.

Should I use it on tap water or RO water?

It is made to polish reverse osmosis water. On tap water the resin is used up many times faster.

Is DI water for drinking?

This cartridge is made for technical water, not as a drinking water filter.

How often should I replace the DI cartridge?

It depends on the dissolved solids in the feed water. The lower the feed TDS, the longer it lasts. Check the output with a TDS or resistivity meter and replace the cartridge when the reading no longer meets your needs.

Which size do I need?

Match the actual size printed on your current cartridge. This cartridge measures 2-7/8 x 20 in and fits a standard 2.5 x 20 in housing. Housings are often named by nominal size, which is slightly larger than the cartridge itself.

How do I replace it?

Turn off the water supply to the filter and release the pressure as your system manual directs. Place a towel or drip pan underneath. Unscrew the housing with the housing wrench and lift out the used cartridge. Fit the new cartridge, turn the water on slowly, check for leaks and flush before first use. Full steps are in the Replacement Schedule tab.

Can I have replacements delivered automatically?

Yes. Choose Subscribe and save when you order and a fresh cartridge arrives on the schedule you set, with 5% off each delivery. You can pause, change or cancel anytime in your account.
